Adjust the power level and frequency: If the Tramp pin cable on VTx is connected with FC, then the button doesn't work.
|
Name |
Reaper Extreme 2.5W V3 |
|
Input Voltage |
9~36V |
|
Output Voltage |
5V |
|
Channels |
80CH |
|
Power |
25mW/200mW/500mW/1.5W/2.5W |
|
Pit |
Double click to enter |
|
Weight |
13g |
|
Mounting Hole |
20*20mm M2 2.8mm depth |
|
Size |
36*27.5*8mm |
|
Consumption |
1.2A/9V |
|
Package Includes |
1 x VTx; 1 x silicon cable; |
|
Band |
CH1 |
CH2 |
CH3 |
CH4 |
CH5 |
CH6 |
CH7 |
CH8 |
|
Band A |
5865 |
5845 |
5825 |
5805 |
5785 |
5765 |
5745 |
5725 |
|
Band B |
5733 |
5752 |
5771 |
5790 |
5809 |
5828 |
5847 |
5866 |
|
Band E |
5705 |
5685 |
5665 |
5645 |
5885 |
5905 |
5925 |
5945 |
|
Band F |
5740 |
5760 |
5780 |
5800 |
5820 |
5840 |
5860 |
5880 |
|
Band R |
5658 |
5695 |
5732 |
5769 |
5806 |
5843 |
5880 |
5917 |
|
Band H |
5653 |
5693 |
5733 |
5773 |
5813 |
5853 |
5893 |
5933 |
|
Band L |
5333 |
5373 |
5413 |
5453 |
5493 |
5533 |
5573 |
5613 |
|
Band U |
5325 |
5348 |
5366 |
5384 |
5402 |
5420 |
5438 |
5456 |
|
Band O |
5474 |
5492 |
5510 |
5528 |
5546 |
5564 |
5582 |
5600 |
|
Band X |
4990 |
5020 |
5050 |
5080 |
5110 |
5140 |
5170 |
5200 |
PIT On/Off:
Double-click the "KEY" button to turn on/off the PIT Mode. Red LED (PWR) off, PIT mode on; Red LED (PWR) on,PIT mode off.
Note:
If tramp cable is connected, button will not work, can not adjust frequency and power, controller will take over.
BetaFlight only can accept 64 channels at most, so need to remove 2 bands before input to BetaFlight.
