1. The PCB adopts high-end 6-layer 1oZ copper skin, and the high-end resin plugged PCB production process is applied, which has strong anti-interference ability.
2. Adopt industrial-grade LDO, high temperature resistance.
3. Use in-line connectors, easy to install, solder-free.
4. The board comes with an in-line programmable magic color LED light, which can switch LED lighting effects freely.
5. Adopt high-quality Japanese Murata capacitors, with strong filtering performance.
6. Eight-way motor control signal output.
7. It comes with multiple seats, which saves time and effort, and is easy to operate.
FC Specifications
Size: 36*36mm (30.5mm-30.5mm mounting hole spacing)
Packing size: 64*64*35mm
Input voltage: 2S-8S Lipo
Product net weight: 8.5g
Package weight: 45g
CPU：STM32F405RGT6
IMU：ICM42688
OSD：AT7456E
Barometer: Integrated
Black box: 16M
BEC：5V/4A
BEC：12V/3A
Serial ports: 6
Firmware version: HAKRC F405V2
Receiver: Frsky / Futaba / Flysky / TBS Crossfire / DSMX: DSM2 receiver
Package includes
1x F405V2 Flight Controller
