Parameter
MCU: AT32F435RGT7
Power supply: 3-6S (11V - 26.1V)
Signal protocol: PWM, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600.
Sensor: ICM-42688-P
Size: 36 * 36mm (30.5 mm installation hole, 4MM diameter)
Firmware version: Betaflight JHEF435
Black box: 16MB
Barometer: SPL06
OSD: Supported
DJI VTX: There is a reserved interface and it is supported.
USB: TYPE-C interface
IIC: Supported
GPS: Supported
Electronic compass: Supported
UART: 4 channels, UART1, 2, 3, 5.
(Note: UART4, 6, and 8 on the flight controller are reserved ports and are not defined in the firmware for the time being.)
BEC: BEC5V/3A and 10V/2A
Receiver: SBUS, IBUS, DSM2/X, TBS, CRSF, etc.
Supports WS2812 programmable LED
Supports buzzer
Built-in voltage sensor with current detection port
Weight: 8.5 grams
